How to Quickly Set up a Benchmark for Deep Learning Models With Kedro?

Author(s): Anh Khoa NGO HO

Originally published on Towards AI.

Photo by AltumCode on Unsplash

As a data scientist, I used to struggle with experiments involving the training and fine-tuning of large deep-learning models. For each experiment, I had to carefully document its hyperparameters (usually embedded in the model’s name, e.g., model_epochs_50_batch_100), the training dataset used, and the model's performance. Managing and reproducing experiments became highly complex during this time. Then, I discovered Kedro, which resolved all my issues. If you are conducting experiments in machine learning, I believe this article will prove immensely beneficial.

What do we need to know about Kedro?

Kedro, an open-source toolbox, provides an efficient template for conducting experiments in machine learning. It facilitates the creation of various data pipelines, including tasks such as data transformation, model training, and the storage of all pipeline outputs. Kedro revolves around three crucial concepts:

  • Data catalog: the data catalog acts as a registry for all sources that the project can use to manage loading and saving data. It includes input datasets, processed datasets, and models. These sources are stored as dictionaries, referred to names (strings), in Yaml files. E.g., in the code below, when we call input_dataset, Kedro returns the csv file in filepath.
type: pandas.CSVDataSet
filepath: data/01_raw/dataset.csv

type: pandas.CSVDataSet
filepath: data/02_intermediate/dataset.csv
  • Node: a node serves as a wrapper for a pure Python function that defines the inputs and outputs of that function. It represents a small step in the pipeline. For example, in data processing, nodes can be defined for tasks like concatenating dataframes or creating new features. Inputs and outputs are sourced from the data catalog.
from kedro.pipeline import node

def process_data(df1, df2):
return df1 + df2

node_process_data = node(func=process_data, inputs=[”input_data”, ”input_data”], outputs=“processed_data”
  • Pipeline: a pipeline consists of a list of nodes where inputs and outputs are interconnected.
from kedro.pipeline import pipeline

pipeline_process_data = pipeline([node_process_data])

Kedro also boasts several valuable plugins: kedro-viz for visualizing data pipelines, kedro-mlflow for facilitating MLflow integration, and kedro-sagemaker for running a Kedro pipeline with Amazon SageMaker, etc., (read more).


This plugin serves as an interactive development tool for visualizing pipelines built with Kedro. It allows the display of dataframes and charts generated through the pipeline, facilitating the comparison of different experiment runs with a single click. In this article, we’ll explore how to track hyperparameters and performance scores of deep learning models using kedro-viz.

Now, let’s delve into creating a benchmark in three steps.

Step 1: set up our experiment

The initial step involves installing the required library, Kedro, along with additional dependencies like PyTorch (build a deep learning model) and kedro-viz, using pip install. For detailed instructions, refer to installing kedro, installing kedro-viz. It's important to note that there are variations between Kedro versions, so we specifically set the version to 0.19.1. Additionally, it is advisable to create a Python environment (consider using conda with the command conda create --name environment_name).

pip install kedro==0.19.1
pip install kedro-viz

pip3 install torch

Creating a project template with necessary files and folders is achieved with the following command (read more):

kedro new

After providing the project name and configuring options, the resulting folder structure includes:

  • conf: This folder keeps our configuration settings for different stages of our data pipeline (e.g., development, testing, and production stage). By default, Kedro has a base and a local environment. Read more.
    base contains the default settings that are used across our pipelines:(a)catalog.yml: this is a default yaml file to describe our data catalog. If we want to create more catalog files, their names must have the format catalog_*.yml. (b)parameters.yml: this is a default yaml file to describe our default parameters. A general format for naming these files is parameters_*.yml.
    local is used for configuration that is either user-specific (e.g. IDE configuration) or protected (e.g. security keys). These local settings can override the settings in the folder base.
  • data: it contains all inputs/outputs of our pipeline (see Data Catalog). Kedro proposes a list of sub-folders to store these inputs/outputs e.g., raw data in 01_raw, pre-processed data in 02_intermediate, trained models in 06_models, predicted data in 07_model_output, performance scores and figures in 08_reporting.
  • docs: this is for documentation. You can use Sphinx to quickly build documentation.
  • logs: we use this folder to keep all logs.
  • notebooks: we put our jupyter notebooks here.
  • src: houses code, including functions, nodes, and pipelines.

To initiate an empty pipeline, utilize the command kedro pipeline create pipeline_name. Subsequently, a folder named pipeline_name is generated, and all created pipeline folders are stored in the directory src/project_name/pipelines. Within a pipeline folder pipeline_name, two essential files are present:

  • contains node functions contributing to data processing.
  • used for constructing the pipeline.

Furthermore, a configuration settings file, parameters_<pipeline_name>.yml, is established in conf/base/ to store parameters specific to the created pipeline. In the subsequent step, we will customize these files to define our pipeline.

Step 2: define our data pipeline

Utilizing a small dataset (sklearn.datasets.load_digits), we define a simple pipeline that involves getting data and storing it locally.

  • In, we define a function to get the dataset.
import pandas as pd
from sklearn.datasets import load_digits

def get_dataset() -> pd.DataFrame:
data = load_digits()
df_data = pd.DataFrame(data['data'], columns=data['feature_names'])
df_data['target'] = data['target']
return df_data
  • In the file src/project_name/pipelines/pipeline_name/, we generate a list of nodes named pipeline_example. Each node comprises func (the function's name, e.g., get_dataset), inputs, and outputs. The nature of inputs and outputs can be a string, a list of strings, or None, depending on the inputs/outputs of the corresponding function. It's important to note that a string denotes a data name that we can later utilize in the subsequent node of our pipeline.
from kedro.pipeline import Pipeline, pipeline, node

from .nodes import get_dataset

def create_pipeline(**kwargs) -> Pipeline:
pipeline_example = [node(
return pipeline(pipeline_example)
  • We define data names in conf/base/catalog.yml and specify their storage details (filepath). There are many options for storing data: local file systems, network file systems, cloud object stores, and Hadoop. Read more.
type: pandas.CSVDataset
filepath: data/01_raw/raw_data.csv

Step 3: define our model

Now, we create our neural network model with PyTorch. We build a simple neural network with 2 feed-forward layers. Recall that the dataset Digits has 64 features and 10 classes. Therefore, the input dimension of our first layer is 64, and the output dimension of our last layer is 10. We add a softmax layer for returning probabilities.

import torch
import torch.nn as nn
import torch.nn.functional as F

class NeuralNetwork(nn.Module):
def __init__(self, dimension):
super(NeuralNetwork, self).__init__()
self.linear_1 = nn.Linear(64, dimension)
self.linear_2 = nn.Linear(32, dimension)
self.softmax = nn.Softmax(dim=1)

def forward(self, x):
x = F.relu(self.linear_1(x))
x = F.relu(self.linear_2(x))
x_prob = self.softmax(x)
return x_prob

The associated functions for the pipeline (e.g., splitting dataset, fitting model, predicting data and evaluating model) are defined in

def split_dataset(df: pd.DataFrame, test_size: float) -> Tuple[pd.DataFrame]:
y = df.pop('target')
X = df

df_X_train, df_X_test, df_y_train, df_y_test = train_test_split(X, y, test_size=test_size)

return df_X_train, df_X_test, df_y_train, df_y_test

def fit_model(df_X: pd.DataFrame, df_y: pd.DataFrame, epochs: int, batch_size: int, dimension: int) -> Tuple[nn.Module, dict]:
model = NeuralNetwork(dimension=dimension)
optimizer = torch.optim.SGD(model.parameters(), lr=0.002)
tensor_X = torch.from_numpy(df_X.to_numpy()).float()
tensor_y = torch.from_numpy(df_y.to_numpy().squeeze())

dataloader = DataLoader(
TensorDataset(tensor_X, tensor_y),

for epoch in range(epochs):
for x, y in dataloader:
y_prob = model.forward(x)
loss = nn.NLLLoss()(torch.log(y_prob), y)

hyperparams = {
'epochs': epochs,
'batch_size': batch_size,
'dimension': dimension

return model, hyperparams

def predict_data(model: nn.Module, df_X: pd.DataFrame, batch_size: int) -> pd.DataFrame:
model = NeuralNetwork()
tensor_X = torch.from_numpy(df_X.to_numpy()).float()

dataloader = DataLoader(

y_predict = []
for x in dataloader:
y_prob = model.forward(x)
y_predict += list(torch.argmax(y_prob, dim=1).detach().numpy())

df_y_predict = pd.DataFrame(y_predict, index=df_X.index, columns=['predict'])

return df_y_predict

def evaluate_model(df_y_test: pd.DataFrame, df_y_predict: pd.DataFrame) -> dict:
f1_score = metrics.f1_score(df_y_test, df_y_predict, average="macro")
precision_score = metrics.precision_score(df_y_test, df_y_predict, average="macro")
recall_score = metrics.recall_score(df_y_test, df_y_predict, average="macro")

scores = {
"f1_score": f1_score,
"precision_score": precision_score,
"recall_score": recall_score,

return scores

Our becomes:

from kedro.pipeline import Pipeline, pipeline, node
from .nodes import get_dataset, split_dataset, fit_model, predict_data, evaluate_model

def create_pipeline(**kwargs) -> Pipeline:
pipeline_example = [node(
inputs=["raw_data", "params:test_size"],
outputs=["X_train", "X_test", "y_train", "y_test"]
inputs=["X_train", "y_train", "params:epochs", "params:batch_size", "params:dimension"],
outputs=["model", "hyperparams"]
inputs=["model", "X_test", "params:batch_size"],
inputs=["y_test", "y_predict"],

return pipeline(pipeline_example)

The nodes split_dataset, predict_data, and evaluate_model yield the following dataframes: X_train, X_test, y_train, y_test, y_predict, and scores. These are specified in conf/base/catalog.yml with a structure analogous to that of raw_data. Additionally, parameters such as test_size, epochs, batch_size, and dimension (the dimension of the hidden layer) are stored in conf/base/parameters.yml.

test_size: 0.2
epochs: 5
batch_size: 10
dimension: 32

The fit_model function produces the trained model, represented as a PyTorch module, which is not a standard component in the Kedro data catalog. Consequently, an AbstractDataset must be defined in this case. Within the src/project_name/pipelines/pipeline_name/ directory, we create a subfolder named extras. Inside this subfolder, a Python file, for instance,, is added. It's essential to include an empty file named to enable Kedro's access to Below is an example of an AbstractDataSet with three crucial functions: _exists, _save, and _load. For the latter two functions, we follow the PyTorch tutorial on saving and loading models under pickle format. While the kedro-mlflow plugin for Kedro can be used to store trained models, this work opts not to employ any additional plugins.

from os.path import isfile
from typing import Any, Dict
import torch
from import AbstractDataset

class TorchModel(AbstractDataset):

def _describe(self) -> Dict[str, Any]:
return dict(filepath=self._filepath)

def __init__(
filepath: str,
) -> None:
self._filepath = filepath

def _exists(self) -> bool:
return isfile(self._filepath)

def _save(self, model) -> None:, self._filepath)

def _load(self):
model = torch.load(self._filepath)
return model

The corresponding catalog entry in conf/base/catalog.yml is:

type: project_name.pipelines.pipeline_name.extras.torch_model.TorchModel
filepath: data/06_models/NeuralNetwork.pickle

Tracking hyperparameters and scores is achieved by storing them as JSON files with tracking dataset type. This is for our benchmark.

type: tracking.JSONDataset
filepath: data/08_reporting/hyperparams.json

type: tracking.MetricsDataset
filepath: data/08_reporting/scores.json

Now, simply enter kedro run in our terminal, and Kedro will execute all discovered pipelines. For larger projects, it is advisable to create distinct pipelines for each task, such as pre-processing data, fitting models, evaluating models, reporting benchmarks, etc. However, in this example, we have chosen to create a single pipeline with all these tasks.

Tracking with Kedro-viz

To activate tracking with Kedro-viz, the following lines of code must be added to

from kedro_viz.integrations.kedro.sqlite_store import SQLiteStore
from pathlib import Path

SESSION_STORE_ARGS = {"path": str(Path(__file__).parents[2] / "data")}

Subsequently, executing kedro viz run in the terminal initializes Kedro-viz. The pipeline is visually represented as a tree structure in Figure 1. This visualization proves beneficial when dealing with large and intricate pipelines, aiding in easily verifying the logic of the pipeline and serving as a valuable tool for explanations.

Figure 1: Visualisation of a data pipeline by Kedro-viz

Kedro also offers the ability to display generated dataframes within the pipeline by incorporating specific properties into the data catalog. When dealing with substantial dataframes, it is essential to adjust the number of rows displayed in the preview tab (learn more).

type: pandas.CSVDataset
filepath: data/01_raw/raw_data.csv
layer: raw
nrows: 5

For experiment tracking, accessing the “chemistry bottle” icon reveals all experiment runs. The “Compare runs (max. 3)” option, situated at the top left of the screen, facilitates quick comparisons between 2 or 3 runs. Additionally, simple metric charts are visible in the “Metrics” tab. In Figure 2, we can see how performance scores of the model change if its dimension changes (from 16 to 32).

Figure 2: Experiment tracking. We can see how our scores changent with our hyperparameters (the dimension is changed from 16 to 32).

It is noteworthy that hyperparams and scores are stored as JSON files (refer to Figure 3). These files can be directly accessed to create more intricate charts for benchmarking. Each run is uniquely identified by a specific name, denoting the date and time of the run.

Figure 3: Tracking files in json format


Kedro offers a robust solution for managing and reproducing experiments in machine learning. The integrated kedro-viz plugin provides visualizations of data pipelines, aiding in the tracking of experiment runs and facilitating comparisons between them. The three-step process outlined in this article demonstrates how to quickly set up a benchmark for deep learning models using Kedro. Experiment tracking with Kedro-viz further enhances the visibility and understanding of the entire pipeline. The code of this project is found in this repo of github.
