Deploying Machine Learning Projects as Serverless APIs

Author(s): Dolu Solana

Originally published on Towards AI.

A guide to deploying Production Ready Data Science Projects as Serverless APIs with Azure Functions.

Introduction

When done right, Machine Learning and Data Science have the potential to help improve business processes, today millions of people have taken the rise of AI as a call to action to create more value for themselves and the world. However, even the most well-built model cannot provide value when left statically in a Jupiter Notebook.

One way to ensure your models are valuable to the business is to make them constantly available, for this, we can expose our models as APIs, these APIs can feed into a larger system i.e a recommendation model feeding into an E-commerce application, or your APIs could feed into a dedicated system or application i.e a segmentation model can feed a web-based dashboard for marketing decision making, and a document extraction model can feed a dedicated internal application for document extraction.

In this article, we would build a simple Azure function that re-trains and applies a K-means model on a retail dataset whenever it’s called.

This article would follow this structure:

1. Standard APIs Vs Serverless APIs: Here we explain what Serverless is.
2. Introducing the Model: We introduce the model we would deploy.
3. Functions In Azure: Demonstrating the process of configuring functions in VS Code.
4. Testing: Then we discuss testing the function locally.
5. Creating Azure Resources for Functions and Deploying: We then demonstrate how to create the resources needed to run the function on Azure.

Standard APIs Vs Serverless APIs

Serverless software refers to any software that abstracts out the hassle of configuring and managing your own infrastructure, you just bring your code and run it, plug and play. The best part; you only pay for what you need.

This is in contrast to Traditional APIs, where you have to configure and manage a server for your code, and this server is always running costs even when the API is idle.

Serverless APIs are a no-brainer in many ways and offer several cost and flexibility advantages over Traditional APIs. So why then do we still use regular APIs? Well, here are some drawbacks of Serverless Computing you should consider when developing a Machine Learning System of your own:

1. Serverless Systems usually have a cold start problem. This means it may take longer than regular API to start and execute a task.
2. They are usually built for short-running tasks that take about 5–10 minutes to run. With some providers allowing up to an hour.

Introducing the Model

Enough theory, in this section we will begin building up to the final cloud function, but first, we have to briefly introduce the model we would be building.

Here we would be using a Segmentation Model, we would assume that a data scientist has already figured out what the optimal parameters would be and all we have to do is to set up the retraining pipeline.

To learn more about developing a clustering model from scratch, check out the references.

The code for retraining has been modularized into four scripts namely:

• get_data.py: Retrieves the data through an SQL query. Here we use pandas' read_sql function to run a query on a given database engine that will be configured in app.py.

import pandas as pd

def get_data(engine):
 # Read in data
 query = """
 SELECT
 Customer_id
 ,Recency
 ,Frequency
 ,MonetaryValue
 ,Customer_Activation_date
 FROM RFM_table
 """
 # call data from try and except block to help debug database errors
 try:
 data = pd.read_sql(query, engine)
 print("connection success")
 except Exception as ex:
 print("Connection could not be made because: \n", ex)

 return data

• preprocess.py: Preprocesses the data, performs feature engineering, and removes unwanted data.

from datetime import datetime
from sklearn.preprocessing import StandardScaler

def pre_process(data):
 #create new column tenure, that represents the number of days since a customer first joined
 data['Tenure'] = (datetime.now() - data['Customer_Activation_date']).dt.days
 data = data.drop("Customer_Activation_date", axis=1)
 data = data[~(data.MonetaryValue < 1)]
 data = data.set_index("Customer_id")

 return data

• train.py: Retrains the model with new data.

# Installing Packages
import pandas as pd
import numpy as np
from sklearn.preprocessing import StandardScaler, FunctionTransformer
from sklearn.cluster import KMeans
from sklearn.pipeline import Pipeline


def train(data, optimal_init):
 # train random init
 koptimal = KMeans(n_clusters=4, init=optimal_init, n_init=1)
 # define transformers
 ## Log transform
 log_transform = FunctionTransformer(np.log)
 # standard scaler
 Scaler = StandardScaler()
 # define pipeline steps
 steps = [("log_transform", log_transform), ("Scaler", Scaler), ("kmeans", koptimal)]
 # define pipeline
 kmeans_pipe = Pipeline(steps=steps)
 # fit model
 kmeans_pipe.fit(data)
 # predict and add cluster labels
 data["cluster_labels"] = kmeans_pipe.predict(data)

 return data

• app.py: Ties all the previous modules together, performs clustering on the data and returns a dataframe with the clusters as a new column. It also contains optimal init parameters.

# Installing Packages
import pandas as pd
import numpy as np
from sklearn.cluster import KMeans
from sklearn.pipeline import Pipeline
from get_data import get_data
from preprocess import pre_process
from train import train
import configparser
from sqlalchemy import create_engine
import pymysql


config = configparser.ConfigParser()
config.read('db.cfg')

# define the database credentials
user = config['<DB_NAME>']['USERNAME']
password = config['<DB_NAME>']['PASSWORD']
host = config['<DB_NAME>']['HOST']
port = config['<DB_NAME>']['PORT']
database = config['<DB_NAME>']['DATABASE']


def get_connection():
 return create_engine(
 url=f"mysql+pymysql://{user}:{password}@{host}:{port}/{database}"
 )


if __name__ == '__main__':
 try:
 # connect to the engine
 engine = get_connection()
 print(f"Connection to the {host} for user {user} created successfully.")
 #the try-except block allows us to debug efficiently.
 except Exception as ex:
 print("Connection could not be made due to the following error: \n", ex)


# set optimal centriod init
optimal_init = np.array([[ 0.53110261, -1.65631567, -0.46662182, -0.36120566],
 [ 0.36156456, 0.35716547, -0.50222171, -0.47586815],
 [-0.09470791, 0.41834683, 1.39116768, 1.17794181],
 [-1.66140645, 0.42296787, -0.10251636, 0.02357708]])

def main():
 RFM = get_data(engine)
 RFM = pre_process(RFM)
 RFM = train(RFM, optimal_init)
 return RFM

• Assess.py (Bonus): Contains a handy set of custom-defined functions that help assess the performance of the clustering model.

# Assess Clusters
def cluster_stats(cluster):
 # Group the data by cluster
 grouped = RFM.groupby(cluster)

 # Calculate average RFM values and segment sizes per cluster value
 return grouped.agg({
 'Recency': ['median',"min", "max"],
 'Frequency': ['median',"min", 'max'],
 'MonetaryValue': ['median', 'min', "max"],
 'Tenure': ["median", "count"]
 }).round(1)


#prepare data for snake plot
normalized_melt = pd.melt(RFM_normalize.reset_index(),
 id_vars=["Customer_id", "cluster_label3", 'cluster_label4', 'cluster_label5'],
 value_vars=["Recency", "Frequency", "MonetaryValue", "Tenure"],
 var_name="Attribute",
 value_name="value")
normalized_melt


#define snakeplot
def snakeplot(df_melt, cluster):
 sns.pointplot(x="Attribute", y='value',hue=cluster, data=df_melt)
 plt.title(f'Snake Plot for {cluster}')

def relative_imp(data, cluster):
 #extract cluster label
 cluster_labels = data.loc[: ,cluster]

 #extract rfm values
 data = data.iloc[:, :4]

 # add cluster labels to rfm values
 data[cluster] = cluster_labels

 # find the average value within cluster
 cluster_mean = data.groupby(cluster).mean()

 #find population mean
 population_mean = data.mean()[:-1]

 #find relative importance score
 relativeimp_score = cluster_mean / population_mean - 1
 relativeimp_score = relativeimp_score.round(2)
 return

Functions In Azure

Now that we have introduced the model and its code. We can begin to talk about converting said code into an Azure function, but first, we have to configure the function. There are several ways to do this, for me the most convenient way would be by using a VS Code extension for function apps. Alternatively, you can also use Azure Command-Line and the Azure Portal. To follow along, you will need:

• An Azure Subscription, you can get a free one here
• Visual Studio Code installed on your system
• A Python Runtime

We can set up our function quickly with the following steps:

1. Download Azure Function Extensions: Go to the extension tab and search for functions, you will see Azure functions come out just click install. (Fig 1.1)

2. Go to the Azure Icon (Fig 1.2), under the resources section chose the option to sign in to your Azure account.

3. While still in the Azure tab, go to the workspaces section and choose “Create New Function”. (Lighting Icon in Fig 1.2)

4. After you click the icon to create a new function, a box will pop up on top of your screen, asking you what folder to create the function project. Chose an empty folder that will store all of your function’s code.

5. After choosing a folder, you will be prompted to pick a language for your function’s runtime, here we pick Python, cause our function’s code is in Python.

6. Next we have to select a Python interpreter, Azure function uses the runtime of the Python interpreter to build a virtual environment for the function. As such, choosing an interpreter from a custom environment you built is best (i.e a Virtual Environment). You can do this by adding the full path to the Python environment.

7. Next we select the trigger type for our function. Triggers are the switch that makes our function run. They can be HTTP-based, Timer based or very much.

8. Next we create a name for our function and choose an authorization level, for learning purposes you can just choose ‘Anonymous’. After this, we are done with the configuration, the function will take a few minutes to complete.

Now, our function has been configured. The VS Code extension for Azure Functions would provide some templates, including configurations as a JSON file and an init file containing the code to ‘initialize’ the function. Now, all we have to do is to add some logic. We would use the code for the model we introduced earlier.

Previously, the code was built to run on our local environment, it was also built to be modular, that is; spread across multiple files where each file performs a logical operation. These files and their logic were all tied together and orchestrated by app.py. However, to convert the code into an Azure function we would need to add each of these Python files to the folder for our function. Also, we would need to convert App.py into a Function init file, this involves three main steps:

1. Import the Azure Functions func object and the logging module (logging is optional but advised).

import azure.functions as func
import logging

2. In the main function definition, accept a func.HttpRequest as an argument and specify func.HttpResponse as an output. i.e

#Former Main function definition
def main()

#New Main Function
def main(req: func.HttpRequest) -> func.HttpResponse:

3. Ensure that the main function returns an HTTP response: Previously our main function returned a data set as a dataframe, now we still want it to return a data set but dataframes can’t be sent over the web(HTTP) as they are, so we must first convert it to a JSON file.

# Former Main Function
def main():
 RFM = get_data(engine)
 RFM = pre_process(RFM)
 RFM = train(RFM, optimal_init)
 return RFM

# New Main Function
def main(req: func.HttpRequest) -> func.HttpResponse:
 logging.info('Python HTTP trigger function processed a request.')
 RFM = pd.read_csv('RFM.csv')
 RFM = pre_process(RFM)
 RFM = train(RFM, optimal_init)
 # convert data to json
 resp = RFM.to_json()
 # make json into Http Response
 return func.HttpResponse(resp)

4. Finally, we convert the name of the file app.py to __init__.py.

Testing the Function.

Now, our function is ready to be tested. To run the function locally we first activate the virtual environment for our project, navigate into our project folder and then run the following prompt in the terminal:

func host start

The above prompt runs the function, and if it runs successfully your terminal should look something like this:

Now the function is running, but still waiting for responses. To actually test the function’s logic we need to call a GET/POST request. We can do this with the help of the Python request function, as seen in the following code segment. I call consume.py:

import pandas as pd
import requests

r = requests.get('http://localhost:7071/api/CusCluster')
rfm_clusters = pd.DataFrame(r.json())
rfm_clusters.to_csv("rfm_clusters.csv")

Deployment

Now that the function has been fully tested, it’s time to deploy it. We can also do this straight from VS Code, however, we need to ensure we have these two components ready:

1. A requirements file: To make sure that all the packages used to run the function locally are available and in their correct versions when deployed, we use a requirement file. To create a requirement file run the code below in the terminal while your virtual machine is activated:

pip freeze > requirements.txt

2. Function App resource in Azure: To deploy the project, we first need to create a function app resource in Azure, you can think of this as a container that holds the environment needed to run the function’s code. We can do this straight from the VS Code IDE by navigating to the ‘Resources’ section of the Azure tab and clicking on the plus icon then following these steps:

A. Select Subscription: You’ll be prompted to choose an Azure Subscription, if you have only one active subscription under your Azure app this step will be skipped.

B. Enter a globally unique name for the function app: Choose a name that can make up a valid URL path. This name would be validated to ensure that it is unique.

C. Select a runtime stack: Choose the language version that you used to run the function locally.

D. Select a location for new resources: Choose a location where your resource will run from, for the best performance, choose a location close to where your function will be called from.

Once our resources are ready, we can deploy the function code by navigating to the Azure tab, in the workspace section select the deploy button(Fig 2.1).

After the deployment is complete, you can click on “View output” to view deployment results.

Now, we have officially built and deployed our first Azure Function.

Conclusions and Next Steps

• In this article, we learned how to create and deploy Azure functions using VS Code, but you can also build it straight from the Azure Portal and with other tools such as IntelliJ, Eclipse, and the Azure Functions Core Tools.
• Here, we discussed building a Serverless API, which is an Azure function with an HTTP trigger, however, Functions can be triggered in a variety of ways. Including Timers, Queues, and even changes in blob storage. Read more here.
• Before deploying to Production, you need to consider certain concepts such as Logging, Security and Monitoring. All of these are streamlined by Azure. You can read more in the documentation here.
• If you encounter any problems running the instructions in this tutorial you can reach out to me on Linkedin.

References

[1] Aurélien Géron, Hands-On Machine Learning with Scikit-Learn, Keras, and TensorFlow, 2019.
[2] Official Documentation for Azure Functions.
