Machine Learning Project in Python Step-By-Step — Predicting Employee Attrition

Author(s): Fares Sayah

Originally published on Towards AI.

AI for Human Resources: Predict attrition of your valuable employees using Machine Learning

Human Resources & AI

An organization’s human resources (HR) function deals with the most valuable asset: people. Human resources play an important role in the success of a business. Human resources face many challenges, and AI can help automate and solve some of these challenges.

AI can help Human Resources with several tasks. In talent acquisition, AI can help by filtering resumes that best fit the job description and talent development by recommending programs that suites each employee’s skills and goals.

On the other hand, AI may face a lot of challenges in HR, like Low volume of historical data, Privacy concerns of employees, and low priority for AI projects.

Predicting Employee Attrition

Employee attrition is one of the major concerns for an HR organization because it will cause losses of expertise, losses of productivity, customer goodwill, hiring costs, training costs, and so on. Employee leaves due to various reasons such as compensation, work satisfaction, performance, supervisors, and so on.

First of all, HR needs to collect comprehensive data about an employee, such as education, salary, experience… We also need data from supervisors such as performance, relationships, promotions…

After that, HR can use this information to predict employees’ tendency to leave and take preventive action.

Exploratory Data Analysis

In-depth EDA can be found in the full notebook: IBM HR AnalyticsU+1F4BCEmployee Attrition & Performance

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 1470 entries, 0 to 1469
Data columns (total 35 columns):
 # Column Non-Null Count Dtype
--- ------ -------------- -----
 0 Age 1470 non-null int64
 1 Attrition 1470 non-null object
 2 BusinessTravel 1470 non-null object
 3 DailyRate 1470 non-null int64
 4 Department 1470 non-null object
 5 DistanceFromHome 1470 non-null int64
 6 Education 1470 non-null int64
 7 EducationField 1470 non-null object
 8 EmployeeCount 1470 non-null int64
 9 EmployeeNumber 1470 non-null int64
 10 EnvironmentSatisfaction 1470 non-null int64
 11 Gender 1470 non-null object
 12 HourlyRate 1470 non-null int64
 13 JobInvolvement 1470 non-null int64
 14 JobLevel 1470 non-null int64
 15 JobRole 1470 non-null object
 16 JobSatisfaction 1470 non-null int64
 17 MaritalStatus 1470 non-null object
 18 MonthlyIncome 1470 non-null int64
 19 MonthlyRate 1470 non-null int64
 20 NumCompaniesWorked 1470 non-null int64
 21 Over18 1470 non-null object
 22 OverTime 1470 non-null object
 23 PercentSalaryHike 1470 non-null int64
 24 PerformanceRating 1470 non-null int64
 25 RelationshipSatisfaction 1470 non-null int64
 26 StandardHours 1470 non-null int64
 27 StockOptionLevel 1470 non-null int64
 28 TotalWorkingYears 1470 non-null int64
 29 TrainingTimesLastYear 1470 non-null int64
 30 WorkLifeBalance 1470 non-null int64
 31 YearsAtCompany 1470 non-null int64
 32 YearsInCurrentRole 1470 non-null int64
 33 YearsSinceLastPromotion 1470 non-null int64
 34 YearsWithCurrManager 1470 non-null int64
dtypes: int64(26), object(9)
memory usage: 402.1+ KB

We notice that ‘EmployeeCount', 'Over18', 'StandardHours' have only one unique value and 'EmployeeNumber' has 1470 unique values. These features aren't useful for us, So we are going to drop those columns.

Conclusions:

• The workers with low JobLevel, MonthlyIncome, YearAtCompany, and TotalWorkingYears are more likely to quit their jobs.
• BusinessTravel : The workers who travel a lot are more likely to quit than other employees.
• Department : The worker in Research & Development are more likely to stay than the workers in other departments.
• EducationField : The workers with Human Resources and Technical Degree are more likely to quit than employees from other fields of education.
• Gender : The Male are more likely to quit.
• JobRole : The workers in Laboratory Technician, Sales Representative, and Human Resources are more likely to quit the workers in other positions.
• MaritalStatus : The workers who have Single marital status are more likely to quit the Married, and Divorced.
• OverTime : The workers who work more hours are more likely to quit than others.

Correlation Matrix

Analysis of correlation results (sample analysis):

• Monthly income is highly correlated with Job level.
• The job level is highly correlated with total working hours.
• Monthly income is highly correlated with total working hours.
• Age is also positively correlated with total working hours.
• Marital status and stock options level are negatively correlated

Data Processing

Converting categorical features to machine-readable data

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 1470 entries, 0 to 1469
Columns: 136 entries, Age to YearsWithCurrManager_17
dtypes: int64(9), uint8(127)
memory usage: 285.8 KB

Checking for duplicate records and features

(1470, 136)
(1470, 136)

92

Applying machine learning algorithms

What defines success?

0.8390022675736961

We have imbalanced data, so if we predict that all our employees will stay we’ll have an accuracy of 83.90%.

===============TRAIN=================
Staying Rate: 83.87%
Leaving Rate: 16.13%
===============TEST=================
Staying Rate: 83.90%
Leaving Rate: 16.10%

Logistic Regression

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[849 14]
 [ 59 107]]
ACCURACY SCORE:
0.9291
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.94 0.88 0.93 0.91 0.93
recall 0.98 0.64 0.93 0.81 0.93
f1-score 0.96 0.75 0.93 0.85 0.92
support 863.00 166.00 0.93 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[348 22]
 [ 43 28]]
ACCURACY SCORE:
0.8526
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.89 0.56 0.85 0.73 0.84
recall 0.94 0.39 0.85 0.67 0.85
f1-score 0.91 0.46 0.85 0.69 0.84
support 370.00 71.00 0.85 441.00 441.00

Random Forest Classifier

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[863 0]
 [ 0 166]]
ACCURACY SCORE:
1.0000
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 1.00 1.00 1.00 1.00 1.00
recall 1.00 1.00 1.00 1.00 1.00
f1-score 1.00 1.00 1.00 1.00 1.00
support 863.00 166.00 1.00 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[362 8]
 [ 63 8]]
ACCURACY SCORE:
0.8390
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.85 0.50 0.84 0.68 0.80
recall 0.98 0.11 0.84 0.55 0.84
f1-score 0.91 0.18 0.84 0.55 0.79
support 370.00 71.00 0.84 441.00 441.00

Fitting 5 folds for each of 648 candidates, totalling 3240 fits
[Parallel(n_jobs=-1)]: Using backend LokyBackend with 4 concurrent workers.
[Parallel(n_jobs=-1)]: Done 42 tasks U+007C elapsed: 16.8s
[Parallel(n_jobs=-1)]: Done 192 tasks U+007C elapsed: 1.1min
[Parallel(n_jobs=-1)]: Done 442 tasks U+007C elapsed: 2.6min
[Parallel(n_jobs=-1)]: Done 792 tasks U+007C elapsed: 4.8min
[Parallel(n_jobs=-1)]: Done 1242 tasks U+007C elapsed: 8.2min
[Parallel(n_jobs=-1)]: Done 1792 tasks U+007C elapsed: 11.8min
[Parallel(n_jobs=-1)]: Done 2442 tasks U+007C elapsed: 15.3min
[Parallel(n_jobs=-1)]: Done 3192 tasks U+007C elapsed: 20.9min
[Parallel(n_jobs=-1)]: Done 3240 out of 3240 U+007C elapsed: 21.3min finished
TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[863 0]
 [ 15 151]]
ACCURACY SCORE:
0.9854
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.98 1.00 0.99 0.99 0.99
recall 1.00 0.91 0.99 0.95 0.99
f1-score 0.99 0.95 0.99 0.97 0.99
support 863.00 166.00 0.99 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[360 10]
 [ 63 8]]
ACCURACY SCORE:
0.8345
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.85 0.44 0.83 0.65 0.79
recall 0.97 0.11 0.83 0.54 0.83
f1-score 0.91 0.18 0.83 0.54 0.79
support 370.00 71.00 0.83 441.00 441.00

Support Vector Machine

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[855 8]
 [ 47 119]]
ACCURACY SCORE:
0.9466
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.95 0.94 0.95 0.94 0.95
recall 0.99 0.72 0.95 0.85 0.95
f1-score 0.97 0.81 0.95 0.89 0.94
support 863.00 166.00 0.95 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[345 25]
 [ 44 27]]
ACCURACY SCORE:
0.8435
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.89 0.52 0.84 0.70 0.83
recall 0.93 0.38 0.84 0.66 0.84
f1-score 0.91 0.44 0.84 0.67 0.83
support 370.00 71.00 0.84 441.00 441.00

Fitting 3 folds for each of 12 candidates, totalling 36 fits
[Parallel(n_jobs=1)]: Using backend SequentialBackend with 1 concurrent workers.
[Parallel(n_jobs=1)]: Done 36 out of 36 U+007C elapsed: 6.6min finished
GridSearchCV(cv=3, estimator=SVC(random_state=42),
 param_grid=[{'C': [1, 10, 100, 1000], 'kernel':['linear']},
 {'C': [1, 10, 100, 1000], 'gamma': [0.001, 0.0001],
 'kernel': ['rbf']}],
 scoring='roc_auc', verbose=1)TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[862 1]
 [ 6 160]]
ACCURACY SCORE:
0.9932
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.99 0.99 0.99 0.99 0.99
recall 1.00 0.96 0.99 0.98 0.99
f1-score 1.00 0.98 0.99 0.99 0.99
support 863.00 166.00 0.99 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[346 24]
 [ 42 29]]
ACCURACY SCORE:
0.8503
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.89 0.55 0.85 0.72 0.84
recall 0.94 0.41 0.85 0.67 0.85
f1-score 0.91 0.47 0.85 0.69 0.84
support 370.00 71.00 0.85 441.00 441.00

XGBoost Classifier

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[863 0]
 [ 0 166]]
ACCURACY SCORE:
1.0000
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 1.00 1.00 1.00 1.00 1.00
recall 1.00 1.00 1.00 1.00 1.00
f1-score 1.00 1.00 1.00 1.00 1.00
support 863.00 166.00 1.00 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[360 10]
 [ 52 19]]
ACCURACY SCORE:
0.8594
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.87 0.66 0.86 0.76 0.84
recall 0.97 0.27 0.86 0.62 0.86
f1-score 0.92 0.38 0.86 0.65 0.83
support 370.00 71.00 0.86 441.00 441.00

LightGBM

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[863 0]
 [ 0 166]]
ACCURACY SCORE:
1.0000
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 1.00 1.00 1.00 1.00 1.00
recall 1.00 1.00 1.00 1.00 1.00
f1-score 1.00 1.00 1.00 1.00 1.00
support 863.00 166.00 1.00 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[357 13]
 [ 53 18]]
ACCURACY SCORE:
0.8503
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.87 0.58 0.85 0.73 0.82
recall 0.96 0.25 0.85 0.61 0.85
f1-score 0.92 0.35 0.85 0.63 0.82
support 370.00 71.00 0.85 441.00 441.00

CatBoost

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[863 0]
 [ 17 149]]
ACCURACY SCORE:
0.9835
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.98 1.00 0.98 0.99 0.98
recall 1.00 0.90 0.98 0.95 0.98
f1-score 0.99 0.95 0.98 0.97 0.98
support 863.00 166.00 0.98 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[361 9]
 [ 58 13]]
ACCURACY SCORE:
0.8481
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.86 0.59 0.85 0.73 0.82
recall 0.98 0.18 0.85 0.58 0.85
f1-score 0.92 0.28 0.85 0.60 0.81
support 370.00 71.00 0.85 441.00 441.00

AdaBoost

TRAINIG RESULTS:
===============================
CONFUSION MATRIX:
[[843 20]
 [ 88 78]]
ACCURACY SCORE:
0.8950
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.91 0.80 0.90 0.85 0.89
recall 0.98 0.47 0.90 0.72 0.90
f1-score 0.94 0.59 0.90 0.77 0.88
support 863.00 166.00 0.90 1029.00 1029.00
TESTING RESULTS:
===============================
CONFUSION MATRIX:
[[344 26]
 [ 52 19]]
ACCURACY SCORE:
0.8231
CLASSIFICATION REPORT:
 0 1 accuracy macro avg weighted avg
precision 0.87 0.42 0.82 0.65 0.80
recall 0.93 0.27 0.82 0.60 0.82
f1-score 0.90 0.33 0.82 0.61 0.81
support 370.00 71.00 0.82 441.00 441.00

Comparing Models Performance

RANDOM FOREST roc_auc_score: 0.543
XGBOOST roc_auc_score: 0.620
LOGISTIC REGRESSION roc_auc_score: 0.546
SUPPORT VECTOR MACHINE roc_auc_score: 0.500
LIGHTGBM roc_auc_score: 0.609
CATBOOST roc_auc_score: 0.579
ADABOOST roc_auc_score: 0.599

Conclusion

In this article, we learned how to develop a machine-learning model to predict employee attrition. We used a variety of ML algorithms, including ANNs and Tree-Based models. The models tend to overfit the training data because of the problem's complexity and the small amount of data.
